NiteVizor VN1-XTR

The NiteVizor VN1-XTR EXTREME features the latest developments in image acquisition technology for the serious hunter and sportsman.

Powered by VizorView, the VN1-XTR EXTREME delivers outstanding image quality day and night. The modular system fits virtually any rifle scope, transforming it into a powerful image acquisition device, including the ability to record full-HD video with audio, save images and produce time-lapse recordings.

When darkness descends, the powerful 850nm VizorView Infrared illumination – virtually undetectable to the naked eye – immediately illuminates the target area in front of where the rifle scope is aiming, allowing fast and clear visibility up to 100 meters (109yards) away*.

The infrared image is then transmitted through the optics of the scope via the eyepiece camera and displayed on the 2.4 inch, fully dimmable, LCD screen.

Fully connected, the NizeVizor VN1-XTR EXTREME allows those precious moments to be saved forever via the removable Micro SD card. WIFI connectivity enables the camera display to be wirelessly transmitted to an iPhone/iOS or Android device with the free app.

Extremely rugged, the system is suitable for use in the most extreme conditions and can be easily installed and removed in seconds. No adjustment is needed when the VN1-XTR EXTREME is mounted, as the camera feed is directly produced from the rifle scope.

SPECIFICATIONS

IR LED: 1x 850nm VizorView Infra-Red Illuminator with IR Cut Filter
Lens: Full Color 1/3 CMOS
LCD: Dimmable Full-HD Color 2.4”
Video Size: Full-HD 1080P, 720p – 30FPS
Audio Recording: Yes
Still Image Size: 12MP, 10MP, 8MP, 6MP
Timelapse Function: Adjustable interval between 1-60 minutes
Distance Range at Night: 100m (subject to weather conditions and scope optics)
WIFI: Yes, with free downloadable app for iOS and Android devices
Display Language: English, German, French, Spanish, Italian, Russian & Japanese

Scope Clamp Size: 25mm, 28mm, 30mm & 35mm
Scope Sleeve Size: 35mm, 40-45mm & 45-50mm
Power: USB Type C Power Bank (included) or 2x 18650 rechargeable batteries (not included)
Video Output: PAL/NTSC
Micro SD card support: Upto 32gb
USB Output: USB 2.0
Operating Time: Up to 15 hours (3 hours with constant IR use)
Operating Temperature: -10°C - +45°C
Weight: 500g excluding batteries
Water Resistance: Standard: IP66
Warranty: 2-year warranty
Conformity: CE, FCC & RoHs approved
